Bodor CT

Classic Model | Sheet&Tube Laser Cutting Machine

Key specifications

Laser power: 3-12 kW
Working area: Sheet 3048 x 1524 mm + Tube up to 6500 mm
Max positioning speed: 130 m/min

Specifications

Technical parameters from Bodor’s official specification.

Parameter	Value
Laser power	3-12 kW
Working area	Sheet 3048 x 1524 mm + Tube up to 6500 mm
Max positioning speed	130 m/min

One Smart Investment for Diverse Needs

High Standard
Manufactured to meet stringent European standards, the CT Series ensures superior quality and reliability. With the protective enclosure, the CT Series delivers you peace of mind. Choose quality that stands the test of time.
Efficient Production
With a fast transmission speed and a high-performance bus servo motor boasting leading dynamic performance, the CT Series significantly increases processing efficiency, allowing you to achieve efficient production.
Cost-Effective
The CT Series minimizes the need for multiple machines by offering sheet and tube-cutting capabilities in a single unit. It is the optimal choice for the best cost-effectiveness.

Cutting Parameter Auto-Match

Visual comparison of sample parts and cutting parameter auto-match enhance cutting quality, and reduce labor costs.

Cutting Parameter Auto-Match

Visual comparison of sample parts and cutting parameter auto-match enhance cutting quality, and reduce labor costs.

The 3rd-Generation Mortise-and-Tenon Welding Bed Frame

The rigidity of the bed frame increased by 30%, and the structural strength enhanced by 25%. *Data obtained from laboratory analysis.

30%↑

Overall Performance

Note: The "Overall Performance Improved by 30%" mentioned above is relative to Bodor's previous-generation product.

1.5G

Max. Acceleration

It adopts high-performance bus servo motors to achieve the absolute leading dynamic performance (compared with similar products in the market), significantly improving processing efficiency to ensure that every second you invest creates value.

Aerospace Aluminum Beam

Weight
30%↓
Structural Strength
25%↑

Laser Head
Intelligent Collision Avoidance

Self-developed servo-following sensors and path avoidance algorithms reduce the risk of laser head collision significantly.

Remnants Layout

By taking a photo of remnants with your phone and uploading the image, you can make the remnant layout a one-click task as the system automatically identifies and quickly locates the corners.

Mineral Cast Anti-Burn Plate

The mineral cast anti-burn plate is heat-resistant and non-conductive, making the machine less prone to deformation, easy to clean, and ensuring a long lifespan.
